Gema Quick Release Coupling for hose - Ø 8/6 mm 203181
These are aftermarket parts, they are not Gema OEM. but 100% compatible with original, made of high quality material for wear-resistence and offer more competitive prices！
OptiFlow powder injector (complete, pos. 1-9) 391 530
1 Injector body (without pos. 2) 1000 132
2 O-ring - Ø 16x2 mm 231 517#
3 Insert sleeve - PTFE 377 724#
4 Hose connection (complete, incl. pos. 4.1) 387 827
4.1 O-ring - Ø 15x1 mm 266 930#
5 Threaded sleeve 387 819
6 Check valve conveying air (red marking) - complete (incl. pos. 8 and 9) 261 211
7 Check valve supplementary air (black marking) - complete (incl. pos. 8 and 9) 261 203
8 Ball 240 168
9 Spring 240 176
14 Quick release coupling red for conveying air hose - Ø 8/6 mm 261 645
15 Quick release coupling for supplementary air hose - Ø 8/6 mm 261 637
16 Conveying air hose - Ø 8/6 mm (red) 103 500*
17 Supplementary air hose - Ø 8/6 mm (black) 103 756*
18 Quick release coupling for hose - Ø 8/6 mm 203 181
Powder hose - type 1001, PUR, Ø 16/11 mm (standard for automatic guns) 103 012*#
Powder hose - type 1004, PVC, Ø 16/11 mm (standard for manual equipment) 103 128*#
Powder hose - type 1005, PVC, Ø 20/12 mm (for manual equipment) 100 080*#
Powder hose - type 66, POE, Ø 16/11 mm, with conductive strip (for automatic guns) 105 139*#
Powder hose - type 74, POE, Ø 15/10 mm, with conductive strip (for automatic guns) 1001 673*#
Powder hose - type 75, POE, Ø 18/12 mm, with conductive strip (for automatic guns) 1001 674*#
